Technical Datas :

Temp.range : -65～+165°C (PE Cable -40～+85°C)

Vibration : MIL-STD-202,Method 213

Impedance : 50Ω

Frequency Range : DC～12.4GHz( 0～18GHz)

Working Voltage : 335V max

Withstand Voltage : 1000V rms

 Center Contact resistance : ≤ 3 mΩ

Outer Contact resistance : ≤ 2 mΩ

Insulation resistance : ≥ 5000 MΩ

VSWR : Straight Flexiable cable : ≤1.10+0.002f , semi-rigid cable ≤1.05+0.001f

VSWR Right angle Flexible cable ≤1.20+0.003f semi-rigid cable ≤1.10+0.001f

Durability(mating) ≥500 cycles

MATERIAL & PLATING

Shell : brass gold plated

Contact pin :  brass gold plated plated

Socket : beryllium gold plated

Elastic contact :beryllium gold plated

Insulator : PTFE

Crimping suite : copper alloy nickel or gold plated

O-ring sealing : sillicone rubber
